SSD PNY CS2241 NVMe 500GB /M.2-2280 / PCIe Gen4x4, Read Up to 4700MB/s Write Up to 1700MB/s - M280CS2241-500-CL

Specification
Usable Capacities
500GB/ 1TB/ 2TB/ 4TB
NAND Components
3D NAND Flash Memory
Interface
PCIe Gen4x 4
Form Factor
M.2 2280
Package Dimensions (L×W×H)
123 x 85 x 4.3 mm
Product Dimensions (L×W×H)
22 x 80 x 4 mm (Max)
Weight
6.6g
Max Sequential Read*
500GB: Up to 4,700MB/s
1TB: Up to 5,100MB/s
2TB, 4TB: Up to 5,000MB/s
Max Sequential Write*
500GB: Up to 1,700MB/s
1TB: Up to 3,200MB/s
2TB, 4TB: Up to 4,200MB/s
TBW
500G: 160, 1TB: 320, 2TB: 640, 4TB: 900
PCIe Link Power Management
PS0/ PS1/ PS2/ PS3/ PS4, APST, ASPM, L1.2
Operating Temperature
0°C to 70°C
Storage Temperature
-40°C to 85°C
Certifications
BSMI, CE, FCC, KCC, REACH, RoHS, VCCI
MTBF
1,500,000 Hours
Error Correction Code
LDPC (Low Density Parity Check) ECC Algorithm
Product Health Monitoring
Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T)
Full End-to-End Data path protection
Supported
Performance Optimization
TRIM (requires OS support)
Warranty
5-Year Limited Warranty or TBW*
