Ổ cứng SSD Kioxia Exceria Plus G4 1TB/2TB NVMe Gen 5x4

• BiCS FLASH™
• NVMe™ 2.0c Technology

• M.2 2280 Form Factor
• PCIe^® Gen5 x4

• SSD Utility Management Software

Speed Only PCIe^® 5.0 Can Provide

Featuring the latest and greatest PCIe^® 5.0 interface, the EXCERIA PLUS G4 SSD series delivers excellent transfer speeds of up to 10,000MB/s for sequential reads and 8,200MB/s for sequential writes. Whether you are loading the latest game or editing the next viral video, this new series will provide the speed you need.

Power Efficiency Prioritized

The EXCERIA PLUS G4 SSD series delivers significantly improved performance without excessive energy or cooling requirements. Designed with efficiency in mind, EXCERIA PLUS G4 SSDs offer low power consumption, reducing the heat generated in your system. These SSDs delivers up to approximately 80% more power efficiency at max sequential read speed over the previous generation EXCERIA PLUS G3 series.^*7

Advanced Heat Dissipation

EXCERIA PLUS G4 SSDs feature innovative product labels to enhance heat dissipation for advanced performance stability.

Cutting-Edge 3D Flash Memory

Each EXCERIA SSD is built with BiCS FLASH™ and a vertically stacked cell structure, delivering a cutting edge storage experience.

SSD Utility Management Software

The SSD Utility management software was designed to help your KIOXIA drive thrive and lets you be in control of maintenance, monitoring and more!

We highly recommend you install and update to the latest version to maximize your drive’s performance and check its Percentage Life Left using the health gauge.

SSD Utility Management Software

EXCERIA PLUS G4 SSD Product Specifications

Capacity / dimensions

• Capacity

  1TB, 2TB

• Form Factor

  M.2 Type 2280-S3-M

• Interface

  PCI Express^® Base Specification Revision 5.0 (PCIe^®)

• Flash Memory type

  BiCS FLASH™ TLC

• Interface Maximum Speed

  128 GT/s (PCIe^® Gen5x4)

• Dimension (Max: LxWxH)

  80.15 x 22.15 x 2.38 mm

• Interface Protocol

  NVM Express™ Base Specification 2.0c

• Weight

  1TB: 5.6 g (typ.)
  2TB: 5.7 g (typ.)

Performance

• Max Sequential Read Speed^*1

  10,000 MB/s

• Max Sequential Write Speed^*1

  1TB: 7,900 MB/s
  2TB: 8,200 MB/s

• Max Random Read Speed^*2

  1,300,000 IOPS

• Max Random Write Speed^*2

  1,400,000 IOPS

• Endurance: TBW^*3

  1TB: 600 TB
  2TB: 1,200 TB

• MTTF

  1.5 million hours

Operating environment / protection performance

• Operating Temperature

  0 ℃ (Ta) to 85 ℃ (Tc)

• Storage Temperature

  -40 ℃ to 85 ℃

• Certification

  RoHS compliant^*5

• Shock Resistance

  9.806 km/s² {1,000 G} 0.5 ms half sine wave

• Vibration

  25.4mm peak-to-peak (10Hz to 20Hz), 20G peak (20Hz to 2000Hz), (20min /Axis) x 3 Axis

• Supply Voltage

  3.3 V ±5 %

• Power Consumption

  PS3: 50 mW (typ.)
  PS4: 5 mW (typ.)

• Power Consumption (Active)

  5.3 W (typ.)

Compatibility

• Connector Type

  M.2 M key Socket

• Target Applications

  Client desktops and laptops

•

Others

• Services and Support

  Up to 5-year manufacturer's warranty^*4

• Performance Optimization

  TRIM, Idle Time Garbage Collection, Host Memory Buffer

Product Info

• 1TB

  PN: LVD10Z001TG8
  EAN: 4582563859975

• 2TB

  PN: LVD10Z002TG8
  EAN: 4582563859982
